Infrared Drive 4Mb FIR 5-Pin Cable

Regular price $6.00



The Infrared Drive's transfer speed, with the standard IR cable, is already at 115.2kbps which is the maximum serial cable transfer speed.

If your motherboard provides support for 4 Mbps FIR (Fast Infrared), the Infrared Drive can deliver up to 4Mbps data transfer speed with the use of the FIR cable.

How fast is 4Mbps ?  It is over 30 times faster than the standard serial port data transfer rate !



N NAME WIRE COLOR DESCRIPTION
1 VCC Red +5v, power
2 FIR Green FIR data receive
3 IRRX* Yellow IR data receive
4 GND Black System GND
5 IRTX White IR data transmit
