Designed to be an ideal easy-to-install replacement power supply choice for most name brand Intel or AMD desktopPC/mini Computer/ Desktop ATX/ PS3TowerPC
SHARK TECHNOLOGY®ATX-400 is a compact 400-Watt power supply with a reduced depth into the PC case to allow for easier installation and free up more room inside the system to facilitate better internal airflow. Strong 80mm turbo fan further ensures hot air inside thesystemis blown out with or without an extra case fan.
Both SATA and Molex 4-pin peripheral power connectors are each laid out on two separate cable lines so drives positioned not adjacent to each other can still be reached.
Supports Intel P3, P4, and newer Core® systems
Supports AMD Athlon, FX, A6, A8, A10, and newer Ryzen™ based systems.
Reliable & will not overheat with strong turbo fan operating at more than 2300 RPM
Safe fan guard design to protect your finger.
Turbo fan provides high airflow exit out from the rear of the PC system
Space saving design allows for easier installation and more airflow inside your PC
Color-coded wiring so you know visually the voltage on each wire going to each power connector
Comes with optional US AC power cord with this purchase
Connectors:
1x 24-pin Main Connector (400mm long cable) 1x 12V (4+4) Power Connector (450mm long cable) 2x Molex 4-pin Peripheral Power Connector (on 2 separate cable lines.) 2x SATA Power Connector (on 2 separate cable lines)
Dimensions: 86(H) x 150(W) x 110 (D) mm
Technical Specifications:
AC INPUT
115V/230V - 60/50Hz
DC OUTPUT
+3.3V
+5V
+12V
-12V
+5VSB
400W
Peak Combined Watts
8A
14A
24A
0.5A
2A
400W
Maximum Power Output: 400W Efficiency: Typical 70% @ full, 50%, or 20% load Mesh fan-guard for child safety protection Input: 100-127V AC or 200-240V AC - select-able by switch
Complete 4*Start system protection: Over Voltage Protection Over Current Protection Short Circuit Protection Over Power Protection
